Tracker Pro 2021

MINI-TUG, Design SF63

Basic functions:
Towing, mooring, pushing and survey operations

TYPE:
Steel hulled, Tug Sea Coastal & River Areas
Hull thickness: Marine grade steel 6 mm

PAINTING SCHEME:
SIGMA paint system

DIMENSIONS:
Length overall: 7.30 m
Beam overall: 2.60 m
Depth at sides: 1.60 m
Draught aft: 0.90 m
Displacement: 8.3 t

TANK CAPACITIES:
Fuel oil: 2 x 250 L (ttl 500 L)
Fresh water: 20L (movable daytank)

PERFORMANCES:
Bollard pull 3.0 t
Speed (max) 12.0 kn

PROPULSION SYSTEM:
Main engines 1 x Cummins (6BTA 5.9M) 370HP

Electric system on board: 12 V
Battery sets 2 x 12 V 120 Ah

PROPELLER:
FPP, steel 4 blades D 710 mm

Deck towing bits, tested for 8 MT
Anchor: 1 x 35 kilo with anchor’s rope 20 meters

GEAR:
Stern A-frame (hydraulic type), lifting capacity max 500 kilo.

NAVIGATION:
Navigations lights
Compass
Fuel indicator
Rudder position indicator
VHF Radio (ICOM)
(*) Optionally: can be installed echosounder with bottom sencor

LIFESAVINGS
4 x life jackets (SOLAS)
2 x liferings (SOLAS)
3 x fire extinguishers CO2
